3
Contents
Warranty
The ninety day warranty herein expressed shall be the exclusive warranty on items
manufactured by seller and shall be in the place and stead of any other warranty, expressed
or implied, including but not limited to the implied warranties of merchantability and fitness for
a particular purpose.
Seller shall not be liable for any loss or damage resulting from delays or non-fulfilment or
orders owing to strikes, fires, accidents, transportation companies or for any reason or
reasons beyond the control of seller or its suppliers.
All warranty claims must be submitted to the seller in writing, within 90 days from date of
shipment, and no returns will be accepted without written permission.
Other provisions hereof notwithstanding, seller shall not be liable for any loss of business
profits or any incidental or consequential damages incurred by Buyer or any third person in
connection with the items or use thereof, however caused.
Unit Warranty
Seller expressly disclaims any warranty express or implied, as to the condition, design,
operation, merchantability or fitness for use of any unit, or part(s) thereof not manufactured
and/or supplied by seller. The only warranties made with respect to such unit or part(s)
thereof are those made by the manufacturer thereof and seller agrees to cooperate with buyer
in enforcing such warranties when such action is necessary. Seller agrees to repair or replace
F.O.B. seller's plant, any unit or part(s) thereof manufactured by it and proved to seller to be
defective due to faulty workmanship or material.
Wiring Diagram for HP21
73401-02000 18
Wiring Diagram for HP41
73400-02000 19
Wiring Diagram for HP51
73403-02000 20
Servicing the Tool
Daily 12
Weekly 21
Every 1200 Working Hours (at least once a year) 21
Service Tools 21
Hydraulic Oil General Safety Data 21
Fault Diagnosis
Symptom, Possible Cause and Remedy 22
Safety Rules 4
Specifications
Intent of Use 5
Tool Specification 5
Tool Dimensions 5
Putting into Service
Principle of Operation 6
Preparation for Use 6
Operating Instructions 6
Mechanical Maintenance
Dismantling the HydraPac 7
Assembly 8-9
Pressure Setting Kits 9
General Assembly and Parts List for HP21
73401-02000 10-11
General Assembly and Parts List for HP41
73400-02000 12-13
General Assembly and Parts List for HP51
73403-02000 14-15
General Assembly and Parts List for
Valve Set 16
Electrical Maintenance
Minor Maintenance 17
Major Maintenance 17
Assembly 17
Avdel UK Limited policy is one of continuous product development and improvement and we reserve the right to change the specification of any product without prior notice.
