5
To convert electrical energy into hydraulic energy that in turn will drive various hand held Hydraulic Powered Tools. The design
pressures of these Tools must be compatible with the working pressures stipulated in the Tool Specifications below.
Model HP21 HP41 HP51
Part Number 73401-02000 73400-02000 73403-02000
Electric Motor 2.2 kW 4 pole flange mount
Power Supply 220/230 V 380/415 V 525 V
1 PH 3 PH 3 PH
50 Hz 50 Hz 50 Hz
Full Load Amps 15.0 A 5.3 A 3.8 A
Working Pressure
Pull 55.2 MPa (8,000 psi)
Return 20.7 MPa (3,000 psi)
Delivery Volumes 2.6 l/min 3.3 l/min 3.3 l/min
Hydraulic Fluid ISO VG 46 OR EQUIVALENT
Pump 4 Cylinder radial
Control 24V dc solenoid controlled directional valve coupled to
a hydrafast combination pressure control and relief valve
Length (L) 815 mm (32")
Height (H) 530 mm (21")
Width (W) 360 mm (14")
Avdel UK Limited policy is one of continuous product development and improvement and we reserve the right to change the specification of any product without prior notice.
Tool Specification
Tool Dimensions
Specifications
Intent of Use
