safety.
Note: this conformity is also valid for the AF45342 activation point and the AF45339 electronic keys.
POWER SUPPLY UNIT
The power supply unit inside the control panel has two outputs:
• Output for the system power supply and the internal battery recharge, 13.8 Vdc (terminal 1).
• Output for recharging the self-powered siren battery 14.5 Vdc (terminal 12)
The power supply unit output is electronically protected against overloads; The total current at the two
outputs must not exceed the maximum value of 280mA. Three protection fuses are also provided for;
• Fuse Fu1 - 0.5A - to protect the siren circuit
• Fuse Fu2 - 0.5A - to protect the system (detectors and remote activation points)
• Fuse Fu3 - 1A - to protect against battery inversion
To make the total rating calculation easier, refer to the following table:
Note: To guarantee autonomy to the system, without mains power, for 24h, do not exceed
the maximum rating value of 50 mA.
OPERATING DESCRIPTION
Refer to page 19 (code AF994) of the present manual for the operating description
Ref. No. Description
Consumption
Quantity
Total
(mA) consumption (mA)
AF53904 4-zone control unit 13 1 13 +
AF45342 Activation/zoning 7
......... ......
+
AF45...60 Flush-mounted PIR detector 0,1
......... ......
+
AF45...62 Flush-mounted PIR detector 7
......... ......
+
AF960 Wall-mounted PIR detector 0,1
......... ......
+
AF962 Wall-mounted DT detector 7
......... ......
+
=
Max value = 50mA ➪
