9
Mini DIN8 Cable Pin Definition
●
Din8 to D-Sub9 Cable Pin Definition
6 7
8
3 4 5
1 2
15
69
No. Signal
1 DTR
2 DSR
3 TXD
4 GND
5 RXD
6 GND
7 NC
8 NC
