The sensor bars (for safety) installed in the cutting zones stop the mechanisation if the bar is
touched. This archetypal safety mechanism is essential in the presence of children.
One press on the sensor
bar (e.g. by a child's arm)
opens the connection of
Terminal A and
immediately stops the
mechanisation.
A : Wiring terminal block
B : Cable tension screw
Product available in DIY hypermarkets
CFI Reference : WEATDT 80301
If installing several sensor bars, the switches must be connected in series (see below)
12. Sensor bars (for safety) OPTIONAL
