6
English
Installation
Required Tools and Materials
• Small slotted screwdriver with 5/64” or 2 mm blade width
— for connecting power when not using Power over
Ethernet.
Camera Package Contents
Ensure the package contains the following:
• Avigilon High Definition IP Dome Camera
• Terminal block
• T20 TORX tamper resistant key
• 4 screws and anchors for solid walls
• Drill template sticker
Installation Steps
Complete the following procedures to install the dome camera.
1. Removing the Dome Cover on page 7
2. Mounting the Dome Camera on page 7
3. Connecting Cables on page 8
4. Assigning an IP Address on page 9
5. Accessing the Live Video Stream on page 9
6. Aiming the Dome Camera on page 10
7. (Optional) Configuring Onboard Storage on page 10
8. Installing the Dome Cover on page 11
9. Focusing the Dome Camera on page 11
10. For More Information on page 12
