l Pink (Reserved) — Unused Wire, do not connect.
l Red (DC) — Auxiliary Power Wire, accepts DC and AC power.
l Black (DC) — Auxiliary Power Wire, accepts DC and AC power.
l 1 — External relay power supply
l 2 — Optional 24 V AC (RMS) or 24 V DC Aux. power supply
Connecting to Power and External Devices 29
