Installation
Camera Package Contents
l
Avigilon H6SL Bullet Camera
l
Junction box
l
Mounting template sticker
l
4 screws and anchors for solid walls
l
4 screws for attachment to electrical box
l
Protective rubber boot for Ethernet port
l
Teflon tape
Installation Steps
Complete the following sections to install the device.
Mounting the Bullet Camera
If the cables for the camera will not be provided from inside the mounting surface, install the junction box first.
After you install the junction box, you can skip directly to step 3 of this procedure.
1. Use the mounting template to drill four mounting holes into the mounting surface.
2. Drill the cable entry hole into the mounting surface then pull the required Ethernet cable through the
cable entry hole.
Installation 10
