Specifications
Camera
Audio Input Line input, A/V mini-jack (3.5 mm)
Video Output NTSC/PAL, A/V mini-jack (3.5 mm)
Lens
H3-DP1: 3-9mm, F1.2, P-iris
H3-DP2: 9-22mm, F1.6, P-Iris
Onboard Storage SD/SDHC/SDXC slot – minimum class 4; class 6 or better recommended
Network
Network 100Base-TX
Cabling Type CAT5
Connector RJ-45
ONVIF
ONVIF compliance version 1.02, 2.00, Profile S (www.onvif.org)
H3A models are also compliant with version 2.4.2 of the Analytics Service Specification
(bounding boxes and scene descriptions not available with third-party VMS)
Security
Password protection, HTTPS encryption, digest authentication, WS authentication, user
access log, 802.1x port based authentication.
Streaming Protocols
IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP,
Zeroconf, ARP RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP,RTP/
RTSP/HTTPS/TCP, HTTP
Mechanical
Dimensions ØxH 167 mm x 157mm (6.6” x 6.2”)
Weight 2.08 kg (4.6 lbs)
Dome Bubble Polycarbonate, clear
Body Aluminum
Housing Pendant mount, vandal resistant
Finish Powder coat, cool gray 2
Adjustment Range 360° pan, 180° tilt, 180° azimuth
Electrical
Power Consumption 9 W
Power Source
VDC: 12 V +/- 10%, 9 W min
VAC: 24 V +/- 10%, 12 VA min
PoE: IEEE802.3af Class 3 compliant
Power Connector 2-pin terminal block
Environmental
Operating
-30 °C to +50 °C (-22 °F to 122 °F)
19 Specifications
