Installation
Required Tools and Materials
l Small slotted screwdriver with 5/64” or 2 mm blade width — for connecting power when not using Power
over Ethernet.
l No. 2 Phillips screwdriver — for attaching camera to an electrical box or wall
l T20 Pin-In Torx driver
Camera Package Contents
Ensure the package contains the following:
l Avigilon™ H4 HD Dome Camera
l Mounting template sticker
l RJ-45 grommet piercing Cap
l 4 screws and anchors for solid walls
l Wall plate
Installation Steps
Complete the following steps to install the camera:
Removing the Dome Cover 9
Mounting and Aiming Video Analytics Cameras 9
Inserting Cables through the Sealing Grommet 9
Mounting the Dome Camera 10
Connecting Cables 11
(Optional) Using the USB Wifi Adapter 12
Assigning an IP Address 12
Accessing the Live VideoStream 12
Aiming the Dome Camera 12
(Optional) Configuring SD Card Storage 13
Installing the Dome Cover 13
Zooming and Focusing the DomeCamera 14
Configuring the Camera 14
