AVL DITEST MCS 120 User Manual

AVL DiTEST MCS 120
Components
User Manual
17
2.1.4 Cable, CAN bus module
Cable to connect the digital cell voltage module via CAN bus.
(with CSC (Cell-Supervision-Circuit).
Fig. 2-13 Cable, symbol photo
WARNING
Use only the referenced accessories from AVL DiTEST!
WARNING
Use the included mains cord set (power cord)!
If the mains cord set has to be changed note the following requirements strictly!
On 240 V mains grid the mains cord set must be designed for a continuous current
of 10 A, on 120 V mains grid the mains cord set must be designed for a
continuous current of 20 A.
The mains cord set must have a C19 plug for the connection to the MCS 120
suitable for the above current ratings.
Connect MCS 120 only to protective contact sockets!
Set up the MCS 120 in a way that there is always free access to the power
separator!
(Power cord from the mains socket).
Version USA: Only oil-resistant cables may be used!
