Components
AVL DiTEST MCS 120
16
User Manual
2.1 Cable sets
2.1.1 USB-cable (USB 2.0 A auf USB 2.0 B Rugged) EX7069
This cable connects the MCS, socket USB, with the PC, socket USB.
Fig. 2-10 USB-Cable USB 2.0 A to USB 2.0 B
2.1.2 Cable Set plus minus, X590
Plus & minus cable with rotatably mounted M6 knurled screw.
Fig. 2-11 Cable Set
2.1.3 Cable, analog module, X590
Cable to connect the analog cell voltage module taps.
(without CSC (Cell-Supervision-Circuit).
Fig. 2-12 Cable, symbol photo
