6.3.1 Language
Access to system settings from the menu to switch the system language between English and Chinese.
6.3.2 Clock
Access to system settings from the menu to switch the real-time clock shown in Analog or Digital.
6.3.3 Clock Time Setting
Connect video switcher to a PC and download a time control software from AVMATRIX official website
www.avmatrix.net/download/ Open the software and click Scan to search and connect the device, then
the clock time will be changed to same time to the PC’s time.
6.4 Network Settings
6.4.1 Network
There are two ways to acquire the IP: Dynamic (IP configured by router) and Static (set IP freely by
yourself). Select the method you need by knob menu. The default setting is Dynamic.
Dynamic: Connecting the video switcher with a router with DHCP features, then it will auto obtain an IP
address automatically. Make sure that the video switcher and PC are in the same local area network.
Static: Select static IP when the PC is without DHCP. Connect the video switcher with PC via network
cable, set the PC’s IP address to the same IP range as video switcher (the video switcher’s default IP
address 192.168.1.215), or set the video switcher’s IP address to the same IP range as PC’s IP address.
6.4.2 Netmask
Set the Netmask. The default setting is 255.255.255.0.
6.4.3 Gateway
Set the Gateway according to current IP address. Save the configuration when network setting finish.
6.5 Video Record
6.5.1 Basic Specification
