v.30_05_2018 4
Installation Guide
When installing the displays please follow the installation manual from the manufacturer for
the type of mount you have selected.
Make sure you use the upper and lower handles on the back of the display while lifting or
moving the display, to avoid touching the front panel during the move.
When unpacking, and carrying the display please follow these guidelines:
• 2 people are needed for displays up to 65”
• 3 people are needed for displays up to 75” & 86”
Before installing, please make sure the wall is strong enough to hold the necessary weight of
the display and the mount.
Step 1. Keep the display facing the ground and place it on a flat object.
Step 2. Remove the 4 screws (M8*15) from the back of the display.
Step 3. Align the mounting arms with the mounting holes and attach the brackets to the
display using the screws removed in Step 2.
Caution: Use max 15mm long screws, 8mm Metric - Longer screws will damage the display
