d. The VAGC Max Gain (dB) field, enter the maximum amount of gain VAGC will apply for receive
audio to remain at or above the VAGC Low Target (dB). Range: 0 to 23 dB. Default: 20 dB.
e.
In the VAGC Threshold (dB) field, enter the minimum decibel level where VAGCbegins to apply gain
to receive audio. Range:–65 to –20 dB. Default:–20 dB.
IMPORTANT
Use caution when setting these fields. Avtec recommends first adjusting the Windows Input
Level (%) and Mic Gain (dB) fields before attempting to adjust any VAGCsetting. Mic Gain (dB)
adjustments should only be made in small increments.
10. Enter the level the Software Media Workstation outputs audio to the external audio interface in the Output
Level (dB) field. Range: –40 to 0 dB.Default:–10 dB.
11. In the Output Level (dB) field, enter the level, as a percentage, of the audio coming from the media workstation
to the external audio interface. Range: 0 to 100. Default: 35.
12. Under the Scout IRR Settings section, from the Audio Payload Type dropdown, select the codec used for
transmitting VoIP audio toward the Scout IRR. Default: G.711.
13. In the Jitter Delay (ms) field, enter the amount of time in milliseconds that the Scout IRR should wait before
decoding VoIP packets from this device. Range: 40 to 2500. Default: 60.
14. From the Voice Activity Detection dropdown, select whether or not the transmission of VoIP packets toward
the Scout IRR is based on the presence of voice in the audio stream. Default: DISABLED.
15. Click Update.
Configuring the Endpoint for NENA Devices
1. From Scout Manager's Configuration tab, in the Endpoints folder, select Add New > Endpoint.
2.
Right-click the new endpoint that displays under the Endpoints folder and select Properties (or double-click the
new endpoint).
The Endpoint Editor dialog box displays.
3.
Configure the endpoint's settings as appropriate. Verify that the Endpoint Profile that you assign to this
endpoint is consistent with the way you want the endpoint to operate.
IMPORTANT
This endpoint is considered a "media workstation endpoint" and not a "VPGate endpoint" because the
interface is directly connected to the console through a USBcable, and not through a VPGate. The Name
you assign to this endpoint should be unique from other VPGate endpoints that are on the same domain.
