5.4.3 DETECTION
ADVANCED CONFIG
C O N N E C T I O N CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9 CH10 CH11 CH12
CH13
CH14
CAMERA
ALARM OFF
DETECTION
ALERT
SENSITIVITY
NETWORK
MOTION ON
DISPLAY
AREA EDIT
RECORD
PRIVACY MASK SETUP
NOTIFY
REGION OF INTEREST SETUP
MULTICASTING
EXIT
1) ALARM
Select N.C./ N.O depending on your installation need. The default alarm value is OFF.
2) SENSITIVITY
Select the detection sensitivity of the selected channel.
3) MOTION
Select if you want to activate the motion detection function for the selected channel (ON/OFF).
4) AREA
Click “EDIT” to set the motion detection area.
There are 16 × 12 grids per camera for all channels. Pink blocks represent the area that is not being detected
while the transparent blocks are the area under detection.
Note: To exit area setting and return to the detection page, right click your mouse.
5) PRIVACY MASK
You can cover certain areas on the camera image with privacy masks.
Note: Up to 20 areas could be added.
PRIVACY MASK
MOSAIC SIZE 8x8
NAME FUNCTION MOSAIC COLOR MOSAIC COLOR TRANSPARENCY
MASK1 OFF OFF ON 0%
MASK2 ON ON ON 25%
ADD EDIT DEL
Select “ADD” to add a new setting, “EDIT” to modify an existing setting, and “DEL” to remove a setting.
ADD / EDIT
PRIVACY MASK - EDIT
NAME MASK3
FUNCTION ON
MOSAIC
ON
COLOR ON
MOSAIC COLOR
TRANSPARENCY 50%
MASK AREA SETUP
To Next Page
