MAIN MENU
27
3) KEY BUZZER
Select to enable or disable the sound when pressing the buttons on the front panel (ON / OFF).
4) VLOSS BUZZER
Select to enable or disable the sound when video loss happened (ON / OFF).
5) MOTION BUZZER
Select to enable or disable the sound when any motion alarm is triggered (ON / OFF).
6) ALARM BUZZER
Select to enable or disable the sound when any internal alarm is triggered (ON / OFF).
7) HDD BUZZER
Select to enable or disable the sound (ON / OFF) when the HDD remaining capacity reaches to the value set
in “HDD NEARLY FULL (GB)”.
8) ALARM DURATION (SEC)
Select the duration time for alarm buzzer in second (5 / 10 / 20 / 40).
9) HDD NEARLY FULL (GB)
If HDD BUZZER is enabled, select the duration time for buzzer notifications when the hard disk available
capacity is 5/10/15/20 GB left.
10) HDD OVERHEAT ALERT (°C)
Select the temperature alert for your hard disk to be aware of the possible overheat of your hard disk.
5.4.5 NETWORK
There are two RJ45 ports on the rear panel: WAN and LAN.
WAN is used to connect this recorder to Internet for remote access from anywhere as long as Internet access is
available.
LAN is used to connect to IP cameras locally.
DDNS is used when the Internet access is available.
Note: For more details about these three functions and network configurations, please get the setup
manual from the supplied CD or from
www.surveillance-download.com/user/network_setup/network_setup_recorder.pdf.
ADVANCED CONFIG
CONNECTION
WAN LAN E-MAIL
DDNS
NETWORK MONITOR SNMP V1/V2 SNMP V3 PROTOCOL
CAMERA
NETWORK TYPE DHCP
DETECTION
IP 192.168.1.112
ALERT
GATEWAY 192.168.1.254
NETWORK
NETMASK 255.255.255.0
DISPLAY
PRIMARY DNS 168.95.1.1
RECORD
SECONDARY DNS 139.175.55.244
NOTIFY
PORT 88
PSE
INTERNET AVAILABILITY ADDRESS www.google.com
MULTICASTING
EXIT
