APPENDIX 4 PRODUCT SPECIFICATIONS
53
APPENDIX 4 PRODUCT SPECIFICATIONS
Hardware
Video Input One LAN port (up to 16 IP cameras)
Video Output HDMI
Video Output Resolution 1920 x 1080
HDD Storage** Ten 4TB HDDs (5 hard disks as a RAID5 array)
eSATA Port YES (1) YES (2)
RS485 Port YES
USB Ports
Two on the front panel:
one for video backup to USB flash drive, and
another for NVR control via a USB mouse
Alarm Out YES
IR Remote Control YES
LAN port 1000Mbps
Ethernet
Internet (WAN) port
1000Mbps
Software
Video Compression Format H.264
Audio Compression Format G.711
Local / Remote Display Mode 16CH
Local / Remote Playback Mode 16CH
Single Channel Playback YES
Recording Mode Manual / Event / Alarm / Schedule
Recording Throughput Up to 480 IPS @ 1920 x 1080, Up to 120Mbps
Pre-alarm Recording YES
Quick Search Time / Event
Event Notification Push Status / Video Mail / Message Mail
Security 4 user access levels with password
Remote Access
(1) Internet Explorer on Windows operating system
(2) EagleEyes on iOS & Android mobile devices
(3) Our self-developed program, Video Viewer
Max. Online User 18
Multicast YES
CMS “Trident" Support YES (E-Map / Health Check / Event Monitor Only)
General
Power Source (±10%) DC19.5V / 7.7A DC19V / 9.47A
Power Consumption (±10%) 28.5W (without a hard disk connected) --
Power Redundancy YES
Operating Temperature
10℃ ~ 40℃ (50℉~104℉)
Dimensions (mm)*** 325.5 (L) x 281.17 (W) x 138.1 (H)
Minimum PC Browsing Requirements
‧Intel core i3 or higher, or equivalent AMD
‧2GB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows 7, Windows Vista & Windows XP, DirectX 9.0 or later
‧Internet Explorer 7.x or later
Used as a disk array to be connected by other NVR
NO YES
Peripherals
HDMI Matrix
* Specifications are subject to change without notice. ** Hard disks are optional *** Dimensional tolerance: ±5mm
