22
APPENDIX 1 PRODUCT SPECIFICATIONS
2 Megapixel 1.3 Megapixel
▓ Network
Network Compression H.264 / MPEG4 / MJPEG
Multiple Video Streaming
(Encode Modes, IPS, Resolution)
3 (H.264, MJPEG, MPEG4)
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols
DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP,
HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, DNS,UDP,IGMP, QoS
Frame Rate 30 FPS
Number of Online Users 10
Security
1. Multiple user access levels with password
2. IP address filtering
3. Digest authentication
Remote Access
1. Internet Explorer on Windows operating system
2. EagleEyes on iPhone, iPad and Android mobile devices
ONVIF Compatible YES
▓ Camera
Image Sensor 1/2.9" SONY H.R. image sensor 1/4" SONY H.R. image sensor
Video Resolution HD1080P / HD720P / VGA / QVGA SXGA / HD720P / VGA / QVGA
Min Illumination 0.1 Lux / F1.5, 0 Lux (IR LED ON)
S/N Ratio More than 48dB (AGC off)
Lens f3.8mm / F1.5
Viewing Angle 83.2°(Diagonal) 62.7°(Diagonal)
IR LED 12 units (10 meters)
IR Shift YES
White Balance ATW
AGC Auto
IRIS Mode AES
POE YES (IEEE 802.3af)
PIR Sensor
Detection Range 76 wide angle with up to 5m long distance at 2.5m height
(under 30C)
External Alarm I/O
YES
External Audio In / Out YES
Power Source (±10%) 12V / 1A 5V / 1A 12V / 1A
Operating Temperature 0℃~40℃
▓ Others
Mobile Surveillance iPad / iPhone / Android mobile device
RTC (real-time clock) YES
Motion Detection YES
Digital Pan / Tilt / Zoom YES
Event Notification FTP / Email / SMS
Minimum Web Browsing Requirements
Pentium 4 CPU 1.3 GHz or hi‧ gher, or equivalent AMD
256 MB RAM‧
AGP graphics card, Direct Draw, 32MB RAM‧
Windows ‧ 7, Vista & XP, DirectX 9.0 or later
Internet Explorer ‧ 7.x or later
* The specifications are subject to change without notice.
** Dimensional tolerance: ± 5mm
