1. OVERVIEW
1.1 Product Features
Easy network setup with your iPhone / iPad
1.3 Megapixel SONY sensor with HDTV 720p quality, allowing users to notice minor details more easily
POE (Power-over-Ethernet) support to eliminate the use of power cables and reduce installation costs
ONVIF standard supported to simplify system integration
External alarm I/O device connection
3-axis mechanism for flexible ceiling and wall-mount installation
Supports external microphone & speaker connection for audio transmission
Remote Surveillance
--
Fully compatibility on iPhone & iPad, and Internet Explorer® on Windows® operating system
1.2 Package Content
□ Network camera □ Screws & Wall Plugs □ 3-pin Terminal
□ Quick Setup with iPhone / iPad □ Adapter (Optional)
□ Audio Cable
1.3 Product Overview
1.4 Connectors
Ethernet: Connect a RJ45 network cable.
DC IN: Connect the regulated power supply, DC 5V or 12V depending on the model you have.
RESET: With the power connected, press to reset all parameters, including the IP address to factory default
settings.
The camera will reboot after default reset. Please do not disconnect your camera during the reset
process.
Alarm I/O: A 3-pin I/O terminal is supplied with the camera for external alarm device connection. For details,
please refer to “1.5 External I/O Port” at page 2.
AUDIO: Plug in the supplied audio cable for speaker and microphone connection.
* The speaker and microphone are not supplied with the sales package and should be purchased separately.
** To know more details about audio cable, please refer to APPENDIX 7 AUDIO SPLITTER CABLE at page 30.
