Axas E4HD - (G) Technical Data

12
User Manual
DVB-S2 DIGITAL RECEIVER
User Manual
(G) Technical Data
The receiver Technical Specifications
Front Standby Button Standby
Rear
Panel
Power switch 1
Sat-IF input 1 x F-type Socket
Video output (analogue) 1 x Cinch-socket(Video)
Video/audio output(digital) 1 x HDMI
Audio output (analogue) 2 x Cinch Sockel
Audio output (digital) Standard optical (SPDIF)
USB 2.0 2
Ethernet 1
Power
AC Adaptor DC 12V 3A
Power consumption
(Max./typ. Operation/stand-by)
36 / 20 / 1W
RF
RF range 950-2150 MHz
Modulation, FEC, de-multiplexer DVB-S / DVB-S2 Standard
Video
Video resolution
CCIR 601 (720 x 576 reihen), 576p,
720p, 1080i
Video decoding MPEG-2, MPEG-4 kompatibel
Input data rate 2 – 45 MSymb/s
S/N > 53 dB
Decoding
Decoding
Digital Audio,MPEG-1, Layer
1, 2, 3
Sampling Rate 32 / 4.1 / 48 kHz
S/N > 65 dB
LNB
LNB supply (vert./horiz.) 13 / 18V; Max. 400mA
Control signal
22kHz; ToneBurst ; DiSEqCTM
1.0 /1.1 / 1.2
General
Dimensions(W x H x D) 175 x 125 x 42 mm
Weight 0.4 kg
