genius
ENGLISH
pag.13
5 REMOTE INTERFACE
Interface to connect the commands for the remote control of some functions of the
genius
and
to control equipment connected to it.
Pin 1 manual error opto out (Emitter NPN optocopuler)
Pin 2 manual error opto out (Common NPN optocopuler)
Pin 3 multiplay opto out (Emitter NPN optocopuler)
Pin 4 multiplay opto out (Common NPN optocopuleR)
Pin 5 audio detect relè COMMON
Pin 6 audio detect relè NORMALY CLOSED
Pin 7 audio detect relè NORMALY OPEN
Pin 8 B left 1°relè NORMALY OPEN
Pin 9 B left 1°relè NORMALY CLOSED
Pin 10 B left 1°relè COMMON
Pin 11 B left 2°relè COMMON
Pin 12 B left 2°relè NORMALY CLOSED
Pin 13 B left 2°relè NORMALY OPEN
Pin 14 MIX command (Anode diodo optocopuler)
Pin 15 MIX command (Kathode diodo optocopuler)
Pin 16 B left command (Anode diodo optocopuler)
Pin 17 B left command (Kathode diodo optocopuler)
Pin 18 B right command (Anode diodo optocopuler)
Pin 19 B right command (Kathode diodo optocopuler)
Pin 20 GND
Pin 21 +15Vcc
Pin 22 –15Vcc
Pin 23 B right relè NORMALY OPEN
Pin 24 B right relè NORMALY CLOSED
Pin 25 B right relè COMMON
6 EXPANDER BUS
The extern Bus is used only in case there are several
genius
connected in chain. The
Expander Bus is the connector which allows reception and transmission of audio signal and
controls on the External Bus.
Pin 1 A right
Pin 2 A left
Pin 3 RDS
Pin 4 Left command B
Pin 5 Right command B
Pin 6 GND
Pin 7 GND
