genius
ENGLISH
pag.15
7.1 INPUTS
genius
features 2 balanced XLR female inputs active with 10KΩ input impedance, and 2
DRAW outputs on PIN RCA to withdraw the A and B input signals.
The A input features a ±10 dB amplification section set using the potentiometer placed on the
front panel.
The B input structure is different: it features a 50 μsec pre-emphasis and a 19 KHz sinusoid
oscillator, both set trough jumper.
The B input features a ±10 dB amplifying section set by through potentiometer on the front
panel, too.
genius
features a bypass hardware which, in case of power failure, will bypass through a relé,
the A input in the output; in case one of the two internal power supplies breaks down the
bypass hardware system starts operating.
genius
A inputs are set ex-works as INDEPENDENT and B inputs are without pre-emphasis
and 19 Khz; setting modifications are left to the user.
We always recommend, when possible, to realise balanced connections with good quality
wires.
