SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual
C h a p t e r 2
Jumpers and Connectors
2.1 Jumpers and Connectors Layout
The following figure shows the layout of all jumpers and
connectors on the SBC82621 CPU card.
