AXIOMTEK SBC82621 - CPU Fan Connector: FAN1 & FAN2; Flat Panel Bezel Connector

SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual
CN6: PC/104 Bus Pin Assignments
Pin# Pin Name Pin# Pin Name Pin# Pin Name Pin# Pin Name
1
GND
2
GND
3
MEMCS16
4
SBHE
5
IOCS16
6
LA23
7
IRQ10
8
LA22
9
IRQ11
10
LA21
11
IRQ12
12
LA20
13
IRQ15
14
LA19
15
IRQ14
16
LA18
17
DACK0
18
LA17
19
DRQ0
20
MEMR
21
DACK5
22
MEMW
23
DRQ5
24
SD8
25
DACK6
26
SD9
27
DRQ6
28
SD10
29
DACK7
30
SD11
31
DRQ7
32
SD12
33
+5V
34
SD13
35
MASTER
36
SD14
37
GND
38
SD15
39
GND
40
(KEY)
2.4.12 CPU Fan Connector: FAN1 & FAN2
Pin Description
1
GND
2
+5V
1
2
3
3
SPEED SENSOR
2.4.13 Flat Panel Bezel Connector
CN3
1357911
2 4 6 8 10 12
