SBC82621 Socket370 Half-size All-in-One CPU Card User’s Manual
Flat Panel Interface Pins for Color DSTN and Color TFT LCD (Twister-T
VT8606)
STN DSTN
Pin
8-bit 16-bit 24-bit 8-bit
LP
LP LP HSYNC HSYNC
FLM
FP FP VSYNC VSYNC
SHFCLK
XCK XCK CK CK
M
DE DE DE DE
ENAVDD
ENAVDD ENAVDD ENAVDD ENAVDD
ENABLK
ENABLK ENABLK ENABLK ENABLK
P0
R0 R0 R0 LR0
P1
G0 G0 G0
P2
B0 B0 B0 LG0
P3
R1 R1 R1
P4
G1 G1 G1 LB0
P5
B1 B1 B1
P6
R2 R2 R2 LR1
P7
G2 G2 G2
P8
B2 B2
P9
R3 R3
P10
G3 G3
P11
B3 B3
P12
R4 R4
P13
G4 G4
P14
B4 B4
P15
R5 R5
P!6
G5
P17
B5
P18
R6 UR0
P19
G6
P20
B6 UG0
P21
R7
P22
G7 UB0
P23
B7
P24
UR1
Jumpers and Connectors
14
