AXISC1004-ENetworkCabinetSpeaker
Productoverview
Productoverview
1
Bracket
2
Logotype(rotatable)
3
Hatch
4
StatusLEDindicator
5
Networkconnector
6
Protectiveearthterminal
7
Microphonedisableswitch
8
SDmemorycardslot
9
Controlbutton
ConnectorsandButtons
ProtectiveEarthTerminal
DANGER
Riskofelectricshock.Theproductshallbegroundedusingagroundingwire.Makesurebothendsofthegroundingwire
areincontactwiththeirrespectivegroundingsurfaces.
Makesurethegroundingwireisasshortaspossibletomakethecurrentpathasshortaspossible.
Networkconnector
NO NO
NO
TICE TICE
TICE
Theproductshallbeconnectedusingashieldednetworkcable(STP).Allcablesconnectingtheproducttothenetworkshall
beintendedfortheirspecicuse.Makesurethatthenetworkdevicesareinstalledinaccordancewiththemanufacturer’s
instructions.Forinformationaboutregulatoryrequirements,seetheInstallationGuideatwww.axis.com.
