Axis Camera Station User Manual

AXIS Camera Station Administration
20 AXIS Camera Station User’s Manual
Click the “...” button to open the Camera Selection view; a non-editable table
containing summarized information on all configured Axis cameras and
network video servers.
Select Camera Switch between available cameras. You will only be able to set up the number
of cameras defined by your license.
Camera Explorer
button
AXIS Camera Station can automatically detect cameras and video servers in
your network.
To detect and add/remove new cameras, click this button to open the Camera
Explorer, a tool that scans a user-defined range of IP addresses and displays
any Axis camera or video server found on the network.
Detect, add or remove cameras in the Camera Explorer
Enable camera Check to enable image capture from the camera. If this checkbox is not
checked when registering a camera, recordings and live-view will not be
possible!
Camera Name The camera’s name as it will appear in the Main window, alarm log and web
page.
1. Enter IP range you wish to scan, e.g.
2. Click
Scan
171.15.115.2 - 171.15.115.254

Axis Camera Station Specifications

General

Category	Video Management Software
Operating System	Windows
Supported Databases	Microsoft SQL Server
User Management	Role-based access control
Mobile App	Yes
Supported Operating Systems	Windows 10, Windows Server 2016, Windows Server 2019
Video Management Features	Live view, recording, playback, event management
Supported Camera Brands	Axis and ONVIF conformant cameras
Integration Capabilities	ONVIF
