AXIS Camera Station Administration
AXIS Camera Station User’s Manual 25
Recordings
All settings that pertain to Recordings are defined under this tab, e.g. :
• motion detection
• recordings triggered by an incoming signal from an input/output
• save recorded images
Select camera Select a camera. For a camera to appear in the drop-down list, it must be
registered under the Cameras tab, see Cameras, on page 19 for instructions.
The maximum number of available cameras is determined by your license.
Recording Method
Continuous recording Check this if you want the server to continuously save images. This option uses
more disk space than recording upon motion-detection or upon an external
alarm.
Record every (seconds) Set the recording rate (1 frame every X seconds). If 0 is selected, the frame rate
specified in the Target recording frame rate (fps) is used.
