PowerConnector
2-pinterminalblockforDCpowerinput.Usea
SafetyExtraLowVoltage(SELV)compliantlimited
powersource(LPS)witheitheraratedoutputpower
limitedto≤100Woraratedoutputcurrentlimited
to≤5A.
AudioConnector
3.5mmaudio
connectors
(stereo)
1Tip2Ring
3
Sleeve
Audio
Input
Microphone/Linein
Balanced:‘Hot’signal
Microphone/Linein
Unbalanced:
Microphone/Linein
Balanced:
‘Cold’signal
Microphone/Linein
Unbalanced:Unused
Ground
Audio
Output
Lineout(mono)
Ground
