Axis F41 - Shorten Sensor Unit Cable

AXISF41MainUnit
7.Ifrequired,attachtheRS232cabletoconnecttoauxiliary
equipment.
ShortenSensorUnitCable
Thesensorunitisdeliveredwithacable.Notethatthiscablecannotbe
extended.Toshortenthecablefollowthesesteps:
1.Cutthecabletothedesiredlength.Measurefromthesensor
unit.
2.Striptheplasticoutercoatingfromtheendofthecable.
3.Peelbacktheshield.
4.Flattenthecoloredwiresintheorderdescribedbelow.
1
Brown
2
White/brown
3
Notused
4
Notused
5
White/blue
6
Blue
NO NO
NO
TICE TICE
TICE
Makesurethatthewiresstayinthecorrectorderandthatthe
cableshieldmakesgoodcontactwiththeconnectorshield.
5.Insertthewiresallthewayintoashielded6P6CRJ12
connector.
6.Useacrimpingtooltofastentheconnectortothecable.
20
