AXISF41MainUnit
Schemadelleconnessioni
ConnettoreI/O
1
2
3
A
B
D
S
G
1
0VCC(-)
2
UscitaCC12V,max50mA
3
Esempio:pulsante
A
I/Oconguratocomeingresso
B
I/Oconguratocomeuscita
79
