AXIS M11 Series Page 5
ENGLISH
LED indicators
Install the hardware
Important!
AXIS M11 Series is designed for indoor and outdoor use. To use the
camera outdoors, install in an approved outdoor housing. Please see
www.axis.com for more information on outdoor housings.
1. Attach the stand to the camera by screwing it on. For wall
mounting, attach the stand to wall first, using 3 appropriate screws.
2. Attach the cable to the network connector (supports PoE class 1) in
the camera.
3. Check that the indicator LEDs indicate the correct conditions. See
table above.
LED Color Indication
Network Green Steady for connection to a 100 Mbit/s network. Flashes
for network activity.
Amber Steady for connection to 10 Mbit/s network. Flashes for
network activity.
Unlit No network connection.
Status Green Steady green for normal operation.
Note: Configure the Status LED to be unlit during normal
operation, or to flash only when the camera is accessed
from Setup > System Options > LED. See the online help
files for more information.
Amber Steady during startup, reset to factory default or when
restoring settings.
Red Slow flash for failed upgrade.
Power Green Normal operation.
Amber Flashes green/amber during firmware upgrade.
