AXIS M3011 - Lens adjustments
Lens adjustments
To adjust the position of the lens, follow these steps:
Open the Live View page in your web browser.
While checking the image in the Live View page, move the lens to the desired position.
Focus
The focus of the AXIS M3011 Network Camera is set at the factory from 0.5m to infinity.
It does not normally need adjustment. To focus on objects closer than 0.5m, or if for
some reason the lens has lost focus, this can be adjusted in the following way:
1. Loosen the lens lock screw.
2. Manually rotate the lens to adjust the focus until the image on the Live View
page is satisfactory.
3. Gently retighten the lens lock screw.
