Axis M3011 User Manual

38
AXIS M3011 - Technical Specifications
Technical Specifications
Function/group Item Specification
Camera Models AXIS M3011
Image sensor ¼” Progressive scan RGB VGA CMOS
Lens • 3.0 mm, F2.0, fixed iris
• Angle of view
horizontal: 66°
vertical: 48°
Light sensitivity 1 lux, F2.0
Shutter time 1/5000 s to 1/4 s
Video Video compression • H.264 Baseline profile
• Motion JPEG
• MPEG-4 Part 2 (ISO/IEC 14496-2)
Resolutions 160x120 to 640x480
Frame rate H.264 • 30 fps in all resolutions
Frame rate MPEG-4
Part 2
• 30 fps in all resolutions
Frame rate
Motion
JPEG
• 30 fps in all resolutions
Video streaming • Multi-stream H.264, MPEG-4 Part 2 and Motion JPEG.
• H.264/MPEG-4 Part 2: 1 stream in full frame rate and resolution. More
streams if identical or limited in frame rate/resolution, max 3 individually
configured streams.
• Motion JPEG: 2 individually configured streams in full frame rate and
resolution. More streams if identical or limited in frame rate/resolution.
• Controllable frame rate and bandwidth
• VBR/CBR H.264 & MPEG-4 Part 2
Image settings • Compression, color, brightness, sharpness, contrast, white balance, exposure
control, exposure zones, backlight compensation, fine tuning of behavior at
low light
• Rotation: 0°, 180°
• Text and image overlay
• Privacy mask
Users • 10 simultaneous users
• Unlimited number of users using multicast (H.264/MPEG-4)
Network Security • Password protection, IP address filtering, HTTPS encryption, network access
control, digest authentication, user access log
Supported protocols IPv4/v6, HTTP, HTTPS, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour,
UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP,
IGMP, RTCP, ICMP, DHCP, ARP, SOCKS.
*This product includes software developed by the Open SSL Project for use in
the Open SSL Tool kit (www.openssl.org)
