Connect the cables
1. Keep the 3.5 mm jack and cut the audio extension cable.
2. Strip the outer cable insulation.
3. Strip the inner wire insulation.
4. Twist the audio wires (with insulation) together.
5. Twist the grounding wires (without insulation) together.
6. Connect the audio wires to the AUDIO IN pin on the camera. See Product overview on page 3.
7. Connect the grounding wires to the GND AUDIO IN pin on the camera.
8. Connect the microphone to the jack of the audio extension cable.
9. Turn on audio and adjust other audio settings in the camera’s webpage.
How to access the product
AXIS IP Utility and AXIS Camera Management are recommended methods for finding Axis products on the network
and assigning them IP addresses in Windows®. Both applications are free and can be downloaded from
axis.com/support The product can be used with the following browsers:
Chrome™ (recommended), Firefox®, Edge®, or Opera® with Windows®
Chrome™ (recommended) or Safari® with OS X®
Chrome™ or Firefox® with other operating systems.
If you need more information about recommended browsers, go to axis.com/browser-support
How to access the product from a browser
1. Start a web browser.
2. Enter the IP address or hostname of the Axis product in the browser’s address field.
To access the product from a Mac computer (OS X), go to Safari, click on Bonjour and select the product from
the drop-down list. To add Bonjour as a browser bookmark, go to Safari > Preferences. If you do not know the
IP address, use AXIS IP Utility to locate the product on the network. For information about how to discover and
assign an IP address, see the document Assign an IP Address and Access the Video Stream on Axis Support
web at axis.com/support
3. Enter your username and password. If this is the first time the product is accessed, the root password must first
be configured.
4. The product’s live view page opens in your browser.
About secure passwords
Important
Axis devices send the initially set password in clear text over the network. To protect your device after the first login,
set up a secure and encrypted HTTPS connection and then change the password.
The device password is the primary protection for the data and services. Axis devices do not impose a password
policy as they may be used in various types of installations. To protect your data we recommend that you:
Change the default password that comes with the devices.
Use a password with at least 8 characters, preferably created by a password generator.
Don’t expose the password.
Change password at a recurring interval, at least once a year.
Set a secure password for the root account
Important
The default administrator user name root cannot be deleted. If the password for root is lost, the device must be reset
to the factory default settings.
1. Make sure to follow the instructions about secure passwords. See About secure passwords on page 5.
2. Type a password and then retype it to confirm the spelling.
3. Click Create a login. The password has now been configured.
Setup
About the product’s built-in help
