2. Select Output in the Port 2 drop-down list.
3. Give the output module a descriptive name, for example, “Gate switch”.
4.
5. To open the gate whenever an event is triggered, select Closed-circuit in the drop-down list.
Create action rules
For the camera to open the gate when the PIR detector senses someone nearby, you need to create an action rule in
the camera:
1. Go to System > Events > Action rules.
2. Click Add.
3. Give the action rule a name, for example, “Open the gate”.
4. From the Trigger drop-down list, select the Input signal.
5. Select Digital input signal.
6. Select “PIR detector”, in this example connected to port 1.
7. Under Actions, select Output port from the Type drop-down list.
8. From the Port drop-down list, select “Gate switch”.
9. Click Ok.
10. Create another action rule with the name “Direct the camera to the gate”
11. Select the same input signal as before, but as action select the previously created “Gate entrance” preset
position.
12. Click Ok.
Applications
About applications
AXIS Camera Application Platform (ACAP) is an open platform that enables third parties to develop analytics and
other applications for Axis products.
To find out more about available applications, downloads, trials, and licenses, go to axis.com/applications
To find the user manuals for Axis applications, go to axis.com
Note
• Several applications can run at the same time but some applications might not be compatible with each other.
Certain combinations of applications might require too much processing power or memory resources when run in
parallel. Verify that the applications work together before deployment.
Troubleshooting
How to reset to factory default settings
Important
Reset to factory default should be used with caution. A reset to factory default resets all settings, including the IP
address, to the factory default values.
To reset the product to the factory default settings:
1. Disconnect power from the product.
2. Press and hold the control button while reconnecting power. See Product overview on page
3. Keep the control button pressed for 1530 seconds until the status LED indicator flashes amber.
4. Release the control button. The process is complete when the status LED indicator turns green. The product
has been reset to the factory default settings. If no DHCP server is available on the network, the default IP
address is 192.168.0.90
5. Use the installation and management software tools to assign an IP address, set the password, and access the
video stream. The installation and management software tools are available from the support pages on
axis.com/support
It is also possible to reset parameters to factory default via the web interface. Go to Settings > System >
