Events
About events
The event pages allow you to configure your product to perform actions when different events occur. For example,
the product can start a recording or send an email notification when a motion is detected. The set of conditions that
defines how and when the action is triggered is called an action rule.
How to direct the camera to a preset position when the camera detects motion
This example explains how to set up the camera to go to a preset position when it detects motion in the image. Make
sure the AXIS Video Motion Detection application is running:
1. Go to Settings > Apps > AXIS Video Motion Detection.
2. Start the application if it is not already running.
3. Make sure you have set up the application according to your needs. Add a preset position:
4. Go to Settings > PTZ and set where you want the camera to be directed by creating a preset position. Create
an action rule:
5. Go to Settings > System > Events > Action rules and add an action rule.
6. Type a name for the action rule.
7. From the list of triggers, select Applications and then select AXIS Video Motion Detection (VMD).
8. From the list of actions, select PTZ Control and then select Preset Position.
9. Select the preset position you want the camera to go to.
10. Click Ok.
How to record video when a PIR detector senses motion
This example explains how to connect an Axis PIR detector to the camera, and set up the camera to start recording
when the detector senses motion. Required hardware
3wire cable (ground, power, I/O)
Axis PIR detector
NOTICE
Disconnect the camera from power before connecting the wires. Reconnect to power after all connections are done.
Connect the wires to the camera’s I/O connector
Note
For information on the I/O connector, see Connectors on page 19
1. Connect the ground wire to pin 1 (GND/-).
2. Connect the power wire to pin 2 (12V DC output).
3. Connect the I/O wire to pin 3 (I/O input).
Connect the wires to the PIR detector’s I/O connector
1. Connect the other end of the ground wire to pin 1 (GND/-).
2. Connect the other end of the power wire to pin 2 (DC input/+).
3. Connect the other end of the I/O wire to pin 3 (I/O output).
Configure the I/O port in the camera’s web page
1. Go to Settings > System > I/O ports.
2. Select Input in the Port 1 drop-down list.
3. Give the input module a descriptive name.
4. To make the PIR detector send a signal to the camera when it senses motion, select Closed-circuit in the drop-
down list.
To trigger the camera to start recording when it receives a signal from the PIR detector, you need to create an action
rule on the camera’s web page.
Use audio to deter intruders
