Axis P1364 User Manual

AXISP1364NetworkCamera
VideoandAudio
Focus
YoucanfocustheAxisproductunderVideo&Audio>Focus.Formostapplications,theadjustmentsontheBasictabaresufcient.
Ifrequired,additionaladjustmentscanbemadeontheAdvancedtab.Beforefocusing,alwaysclickOpeniristoopentheiristoits
maximum.Thisgivesthesmallestdepthofeldandthusbestconditionsforcorrectfocusing.ClickEnableiriswhennishedfocusing.
Basic
Followtheon-screeninstructionsontheBasictabtoadjustzoomandfocus.Thepixelcounterisusedtodeterminethenumberof
pixelsinanareaoftheimage,forexampletoensurethattheimagesizefulllsspecicrequirements.Topositionthepixelcounter,
clickonthetextanddragthewindowtothedesiredposition.
Note
•Thebackfocus(step2)shouldonlyberesetifthecamerahasbeenfocusedpreviously.
•Setfocusaspreciselyaspossibleusingthefocuspulleronthelens(step3)beforestartingtheautomaticne-tuning(step4).
•Ifthecameraisplacedsothatitisdifculttolookattheimageandmovethepullersatthesametime,youcanusethe
FocusAssistanttofocusthecamera;forinstructions,seetheInstallationGuidesuppliedwiththeproduct.
Advanced
Thetoolsonthispagecanbeusedtondtheoptimalfocusposition.Alwaysopentheirisbeforefocusingandenableitwhennished
focusing.FocusismeasuredinthepartoftheimagecoveredbytheFocuswindow.Usethemousetomoveandresizethewindow
andthenclickFine-tunefocusautomatically.Ifneeded,clickintheFocuspositionbaroronthearrowsattheendsofthebar,to
furtheradjustthefocus.Thebuttons<and>movethefocuspositiononestepineitherdirection.Thebuttons<<and>>movethe
focuspositionmultiplestepsineitherdirection.Clickingonthebarsetsfocustothatposition.
PrivacyMask
Aprivacymaskisanareaofsolidcolorthatprohibitsusersfromviewingpartsofthemonitoredarea.Privacymaskscannotbe
bypassedviatheVAPIX®ApplicationProgrammingInterface(API).
ThePrivacyMaskList,Video&Audio>PrivacyMask,showsallthemasksthatarecurrentlyconguredintheAxisproductand
indicatesiftheyareenabled.
SincethePan/Tilt/Zoomcoordinatesdeneitssizeandposition,aprivacymaskisdynamicinrelationtothemonitoredarea.This
meansthatregardlessoftheangleandzoomofthelens,thesameplaceorobjectwillbehidden.Todeneatwhatmagnicationthe
maskshouldbedisplayed,zoomtothedesiredlevelandclickSetlevel.
Youcanaddanewmask,re-sizethemaskwiththemouse,chooseacolorforthemask,andgivethemaskaname.
Formoreinformation,seetheonlinehelp
.
Important
Addingmanyprivacymasksmayaffecttheproduct’sperformance.
SetUpAudio
Tochangetheproduct’saudiosettings,gotoVideo&Audio>AudioSettings.
Eachstreamproleisaseparatevideostream.Toincludetheaudiostreaminallstreamproles,gototheaudiotabineachstream
prolesettingspageandenableaudio.Formoreinformation,seeStreamProlesonpage23.
Ifyouhaveenabledviewareas,rememberthateachviewareaisaseparatevideostream.Toincludetheaudiostreaminallview
areas,gototheaudiotabineachvideostreampageandenableaudio.FormoreinformationseeViewAreaonpage26.
AudioModes
TheAxisproductsupportsthefollowingaudiomodes:
•Fullduplex–Simultaneoustwo-wayaudioallowingtheAxisproducttotransmitandreceiveaudioatthesametime.
29

Axis P1364 Specifications

General

Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/3 \
Bundled software	AXIS Camera Companion, AXIS Camera Station
Number of cameras	1
Focal length range	2.8 - 8.5 mm
Camera shutter speed	1/28000 - 2 s
Minimum illumination	0.1 lx
Form factor	Bullet
Mounting type	Desk
Product color	White
Housing material	Zinc
Lens mount interface	CS mount
Type	IP security camera
Certification	EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, C-tick AS/NZS CISPR 22 Class A, KCC KN22 Class A, KN24, IEC/EN/UL 60950-1
Languages support	CHI (SIMPL), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Number of languages	10
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Maximum resolution	1280 x 960 pixels
Supported video modes	720p
Image quality adjustment	Brightness, Colour depth, Contrast
Video compression formats	H.264, M-JPEG, MPEG4
Audio system	2-way
Voice codecs	G.711, G.726
Alert notification type	E-mail
Password protection type	-
Wi-Fi	No
Networking standards	IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4/v6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Flash memory	256 MB
Internal memory	512 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Power source type	PoE
Power consumption (max)	7.4 W
Power consumption (typical)	4.1 W
Power consumption (Power over Ethernet (PoE))	4.3 W
Operating temperature (T-T)	0 - 55 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	78 mm
Width	205 mm
Height	46 mm
Weight	630 g
