AXISP3818-PVENetworkCamera

Speciﬁcations

I/Oconnectortables

FunctionPinNotes

Specications

DCground

0VDC

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

12VDC

Maxload=50mA

DigitalinputorSupervisedinput–Connecttopin1toactivate,or

leaveoating(unconnected)todeactivate.Tousesupervisedinput,

installend-of-lineresistors.Seeconnectiondiagramforinformation

abouthowtoconnecttheresistors.

0tomax28VDC

Congurable

(InputorOutput)

3–4

Digitaloutput–Internallyconnectedtopin1(DCground)when

active,andoating(unconnected)wheninactive.Ifusedwithan

inductiveload,e.g.,arelay,connectadiodeinparallelwiththeload,

toprotectagainstvoltagetransients.

0tomax28VDC,opendrain,

100mA

Example

DCground

DCoutput12V,max50mA

I/Oconguredassupervisedinput

I/Oconguredasoutput
