Axis P5514-E Installation Guide

AXISP55-ENetworkCameraSeries
3.Toreplacetheclear/smokeddomecover,seepage14.ToinstallanSDcardseepage14.
4.Putthetopcoverbackinitsoriginalpositionandfastentwodiagonallyoppositescrews
rst(torque<0.7Nm),andthenthetwootherscrews.
ReplacetheDomeCover
Important
Thisproducthasadehumidifyingmembranetomaintainlowhumiditylevelsinsidethe
dome.Toavoidcondensation,donotdisassemblethecamerainrainorindampconditions.
Note
Becarefulnottoscratchordamagethedomecover.Ifpossible,keeptheprotectiveplastic
onthedomecoveruntiltheinstallationiscomplete.
Replacingthedomecoverisonlynecessaryifyouwanttouseasmokeddomecoverorifthe
domecoverisscratchedordamaged.Smokeddomecoversandsparecleardomecoverscanbe
purchasedfromyourAxisreseller.
SeeHardwareOverviewonpage9forlocationofcomponents.
1.Loosenthetopcoverscrewsandremovethetopcover.
2.Removethe8domeringscrewsandremovethedomeringfromthetopcover.
3.Attachthedomeringandthereplacementdomecovertothetopcoverandsecureby
tighteningthescrews(torque0.4to0.6Nm).
4.ToinstallanSDcard(notincluded),seepage14.
5.Putthetopcoverbackinitsoriginalpositionandfastendiagonallytwooppositescrews
(torque<0.7Nm),andthentheotherscrews.
InstallanSDCard
NO NO
NO
TICE TICE
TICE
Topreventcorruptionofrecordings,theSDcardshouldbeunmountedbeforeitisejected.
Tounmount,gotoSetup>SystemOptions>Storage>SDCardandclickUnmount.
ItisoptionaltoinstallastandardorhighcapacitySDcard(notincluded),whichcanbeusedfor
localrecordingwithremovablestorage.
SeeHardwareOverviewonpage9forlocationofcomponents.
1.Removethesunshield.
2.Loosenthe4topcoverscrewsandremovethetopcover.
3.InsertanSDcard(notincluded)intotheSDcardslot.
14
