Page 12 AXIS P5544 Installation Guide
Install the Hardware
• Do not lift the Axis product, the top cover or the dome cover by the panopsis lens.
• Be careful not to scratch or damage the dome cover. Use a soft cloth to wipe clean before
attaching the dome cover to the camera unit.
Prepare for Installation
Read all the instructions before preparing to install the Axis product since several installation
preparation steps require removing the top cover and would benefit from being completed together.
• Follow the instructions Remove the Protective Packaging, below to remove the protective
packing before installing the camera.
• A standard or high capacity SD card (not included) can be used for local recording with
removable storage. Follow the instructions Install an SD Card (not included), below to
remove the top cover and install an SD card.
Remove the Protective Packaging
1. Loosen the 4 top cover screws and remove the top cover, see illustration on page 7.
2. Remove the protective packaging. Keep the protective packaging in case of future
transportation.
3. If installing an SD card, refer to the instructions Install an SD Card (not included), below.
4. Put the top cover back in its original position and fasten the screws cross-wise (torque 2.0 -
2.5 Nm).
