Axis P5544 User Manual

AXIS P5544 Installation Guide Page 5
ENGLISH
AXIS P5544
Installation Guide
This Installation Guide provides instructions for installing an AXIS P5544 PTZ Dome Network
Camera on your network. For all other aspects of using the product, please see the User Manual
available at www.axis.com
Installation Steps
1. Check the package contents against the list below.
2. Hardware overview. See page 6.
3. Install the hardware. See page 12.
• Prepare for installation, see page 12.
• Hard ceiling mount, see page 13; drop ceiling mount, see page 14; bracket mount (optional
accessory), see page 16.
• Install the midspan, see page 17.
4. Access the Axis Product. See page 18.
• Calibrate the PTZ mechanics, see page 18.
• The Live View page, see page 18.
Package Contents
Item Models/variants/notes
Network camera AXIS P5544
Mounting kit Mounting kit for hard ceilings and drop ceilings
Resitorx screw driver
High PoE Midspan AXIS T8123
CD Installation and Management Software CD, including installation tools and
other software
Printed materials AXIS P5544 Installation Guide (this document)
Axis Warranty Document, Drill template, Extra serial number labels (2x)
AVHS Authentication key
Optional accessories AXIS T91A Mounting Accessories
Multi-connector cable for connection of I/O, audio, and power
See www.axis.com for information on available accessories

Axis P5544 Specifications

General

Brand	Axis
Model	P5544
Category	Security Camera
Language	English
