AXIS P8221 - Index
41
Index
A
Active/Inactive 18, 20
Administrator 12, 23
Alarm 33
AMC 6
ARP/Ping 25
Audio input 14
Audio output 15
Audio Settings 14
AXIS Media Control 7, 14
AXIS Media Control toolbar 8
B
Bonjour 6
C
CGI link 19
Control Button 31
D
Date & Time 24
Digital input 33
Digital output 33
DNS Configuration 26
DNS Server 26
Domain Name 26
E
Echo cancellation 14
Emergency Recovery 35
Enable ARP/Ping 25
Event Servers 21
Events 21
H
Host Name 26
HTTP Server 21
HTTPS 7, 23, 26
I
I/O connectors 33
IEEE 802.1X 23
Input 33
Input port 17
IP Address Filtering 23
L
Live View 6, 8
Live View Config 19
Logs & Reports 29
N
NAT traversal 6, 26
Network Settings 25
NTP Server 24
O
Output 33
Output Buttons 20
Output port 17
P
Pulse 18, 20
Q
QoS (Quality of Service) 27
R
Recovery 35
Restore 29
RS-232/485/422 connector 32
S
Security 23
Serial port 32
Server Time 24
SNMP 28
Support 29
System Options 23
T
TCP Server 21
TCP/IP Settings 25
Time Mode 24
Troubleshooting 35
U
Upgrade Server 29
UPnP 28
Users 23
V
VAPIX 19

Axis P8221 Specifications

General

Relay Outputs	2
Digital Inputs	4
Enclosure	Plastic
Audio Output	Terminal block for one balanced audio output
Power over Ethernet	Yes
Connectors	Terminal block
Power	PoE (IEEE 802.3af)
Protocols	HTTP, HTTPS, SSL/TLS, IPv4, IPv6, Bonjour, UPnP, QoS, SNMP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, DNS
Network Interface	10/100 Mbit/s Ethernet
Output channels	2
Input type	Digital, audio
Maximum load voltage per output	30 V DC
Operating Temperature	-10 °C to 50 °C (14 °F to 122 °F)
Dimensions (alternative)	4.3 x 2.9 x 1.4 in
Weight (alternative)	0.3 lb
