AXIS P8221 - Overview
Hardware overview
For descriptions of the connectors, please refer to Unit connectors, on page 32.
Network connector (PoE)
Gain control
Control button
Power connector
Audio 2: terminal connector
Audio 1: Audio in/out
I/O terminal connectors A & B
RS-232/485/422 terminal connector
Mounting hole
LED indicators for:
microphone power,
power,
status,
network,
microphone level
Mounting hole
