Axis Q1700-LE User Manual

AXISQ1700-LELicensePlateCamera
Configureyourdevice
2.SelectImageandclick.
3.ClickImages.
4.Draganddropanimage.
5.ClickUpload.
6.ClickManageoverlay.
7.Selecttheimageandaposition.Youcanalsodragtheoverlayimageintheliveviewtochangetheposition.
Setuprulesforevents
Youcancreaterulestomakeyourdeviceperformanactionwhencertaineventsoccur.Aruleconsistsofconditionsandactions.
Theconditionscanbeusedtotriggertheactions.Forexample,thedevicecanstartarecordingorsendanemailwhenitdetects
motion,orshowanoverlaytextwhilethedeviceisrecording.
Tolearnmore,checkoutourguideGetstartedwithrulesforevents.
Triggeranaction
1.GotoSystem>Eventsandaddarule.Theruledeneswhenthedevicewillperformcertainactions.Youcanset
uprulesasscheduled,recurring,ormanuallytriggered.
2.EnteraName.
3.SelecttheConditionthatmustbemettotriggertheaction.Ifyouspecifymorethanoneconditionfortherule,allofthe
conditionsmustbemettotriggertheaction.
4.SelectwhichActionthedeviceshouldperformwhentheconditionsaremet.
Note
Ifyoumakechangestoanactiverule,therulemustbeturnedonagainforthechangestotakeeffect.
Note
Ifyouchangethedenitionofastreamprolethatisusedinarule,thenyouneedtorestartalltherulesthatusethat
streamprole.
Showatextoverlayinthevideostreamwhenthedevicedetectsanobject
Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthedevicedetectsanobject.
1.Starttheapplicationifitisnotalreadyrunning.
2.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.
Addtheoverlaytext:
1.GotoVideo>Overlays.
2.UnderOverlays,selectTextandclick
.
3.Enter#Dinthetexteld.
4.Choosetextsizeandappearance.
5.Topositionthetextoverlay,click
andselectanoption.
10

Axis Q1700-LE Specifications

General

Sensor type	CMOS
Progressive scan	Yes
Number of sensors	1
Optical sensor size	1/2.8 \
Optical zoom	8 x
Focal length range	18 - 137 mm
Maximum aperture number	4.1
Minimum aperture number	2.9
Cables included	LAN (RJ-45)
Type	IP security camera
Certification	EN 55032 A, EN 50121-4, IEC 62236-4, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B A, ICES-003 A, VCCI A, RCM AS/NZS CISPR 32 A, KCC KN32 A, KN35, EAC IEC/EN/UL 62368-1, IEC/EN/UL 60950-22 IS 13252 EN 50581, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10 body, IK08, NEMA 250 4X, NEMA TS 2 NIST SP500–267 EN/IEC 62471
Languages support	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, KOR, POR, RUS
Number of languages	11
Placement supported	Outdoor
Connectivity technology	Wired
Camera shutter speed	1/66500 - 1 s
Minimum illumination	0.03 lx
Detection distance	100 m
Security algorithms	EAP-TLS
Bit rate control	Variable Bit Rate (VBR)
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	AVC, H.264, M-JPEG
Voice codecs	G.711, G.726, PCM
Audio formats supported	AAC
Wi-Fi	No
Networking standards	IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4, IPv6 USGv6, HTTP, HTTPSa , SSL/TLSa , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP
IK code	IK08
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Gray
Housing material	Plastic
International Protection (IP) code	IP66
Flash memory	512 MB
Internal memory	1024 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Power source type	DC, PoE
Power consumption (Power over Ethernet (PoE))	12.95 W
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	50 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 100 %
Harmonized System (HS) code	85258900

Weight and Dimensions

Length	439 mm
Weight	2400 g
Diameter	147 mm
