Axis Q1775 User Manual

AXISQ1775NetworkCamera
PTZ(PanTiltZoom)
TourRecording
Theguardtourfunctioninthisproductincludestourrecording,whichallowsrecordingofacustomtourusinganinputdevicesuchas
ajoystick,mouse,keyboardorthroughtheVAPIX®ApplicationProgrammingInterface(API).Arecordedtourisareplayofarecorded
sequenceofPan/Tilt/Zoommovements,includingtheirvariablespeedsandlengths.
1.GotoPTZ>GuardTourandclickAdd.
2.SelectCreatearecordtourandclickOK.
3.Enteradescriptivename.
4.Specifythepauselengthbetweenruns.
5.Click
tostartrecordingthePan/Tilt/Zoommovements.
6.Whensatised,click
.
7.ClickOK.
Note
Onlythenameoftherecordedtourandpausebetweenrunscanbemodied.Startinganewrecordingwilloverwritethe
existingguardtour.
TherecordedtourcanbeactivatedfromtheLiveViewandGuardTourpagesorthroughevents.Formoreinformationseethe
onlinehelp
.
Advanced
Controls
AdvancedPTZsettingscanbeconguredunderPTZ>Advanced>Controls.
ThePanelShortcutCommandButtonslistshowstheuser-denedbuttonsthatcanbeaccessedfromtheLiveViewpage’sCtrl
panel.ThesebuttonscanbeusedtoprovidedirectaccesstocommandsissuedusingtheVAPIX®applicationprogramminginterface.
ClickAddtoaddanewshortcutcommandbutton.
ThefollowingPTZcontrolsareenabledbydefault:
•Pancontrol
•Tiltcontrol
•Zoomcontrol
Todisablespeciccontrols,deselecttheoptionsunderEnable/Disablecontrols.
Note
DisablingPTZcontrolswillnotaffectpresetpositions.Forexample,ifthetiltcontrolisdisabled,theproductcanstillmoveto
presetpositionsthatrequireatiltmovement.
InstallPTZDriver
ThisAxisproductsupportsseveralPTZdevices.Pleaseseewww.axis.comforacompletelistofsupporteddevices,andtoobtainthe
correctdriver.ToinstallaPTZdeviceyouneedtoinstallthePTZdriver.
ToinstallthePTZdrivergotoPTZ>DriverSelection.Browsetondthedriver(e.g.driver.ptz)andUpload.Ifthedriverwas
successfullyuploaded,itappearsintheSelectdrivertousedrop-downlist.Fromthisdrop-downlist,selectthedrivertoinstall
orremove,andclickSave.
30

Axis Q1775 Specifications

General

Type	IP security camera
PTZ control	Yes
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Box
Mounting type	Desk/Wall
Product color	Black, Silver
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG, MPEG4
Image quality adjustment	Brightness, Sharpness
Analog signal format system	NTSC, PAL
Camera shutter type	Electronic
Camera shutter speed	1/10000 s
Minimum illumination	0.05 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Optical zoom	10 x
Focus adjustment	1.8 - 3.4
Focal length range	3.8 - 38 mm
Audio system	2-way
Voice codecs	G.711, G.726
Built-in microphone	No
Audio formats supported	AAC, ADPCM, G.711, PCM
Flash memory	128 MB
Internal memory	512 MB
Compatible memory cards	SD, SDHC, SDXC
LED type	IR
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet interface type	Fast Ethernet
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS, FTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Interface	RJ-45
Ethernet LAN (RJ-45) ports	1
Power source type	PoE
Power consumption (typical)	9.3 W
Power consumption (Power over Ethernet (PoE))	11.2 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	182 mm
Width	79 mm
Height	59 mm
Weight	1085 g
