AXISQ1942-EPTMountThermalNetworkCamera
Hardwareoverview
Hardwareoverview
Forspecicationsofthehardwarecomponents,seeTechnicalspecicationsonpage55.
NO NO
NO
TICE TICE
TICE
NeverremoveboththesunshieldandthePTMountbracket.Oneofthemmustremaintokeepthecameraassemblyintact.
1
Sunshield
2
RS485/RS422connector
3
Powerconnector
4
Networkconnector
5
Backcover
6
StatusindicatorLED
7
microSDmemorycardslot
8
Controlbutton
9
PTMountbracket
7
