AXISQ6044PTZDomeNetworkCamera

Multi-ConnectorCable(soldseparately)

WhenconnectingexternalequipmenttotheAxisproduct,amulti-connectorcable(availablefromAxis)isrequiredinorderto

maintaintheproduct’sIPrating.Themulti-connectorcablecanbepurchasedfromyourAxisreseller.

Connectthemulti-connectorcabletotheproduct’smulti-connector.Tolocatethemulti-connector,seeHardwareOverviewonpage

6.Thecableprovidesthefollowingconnectors:

Powerconnector-3-pinterminalblockusedforpowerinput.Seeimagebelow.UseaSafetyExtraLowVoltage(SELV)compliant

limitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutputcurrentlimitedto≤5A.

Audioin(pink)-3.5mminputforamonomicrophone,oraline-inmonosignal(leftchannelisusedfromastereosignal).

Audioout(green)-3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoranactivespeaker

withabuilt-inamplier.Astereoconnectormustbeusedfortheaudioout.

I/Oterminalconnector-Usewithexternaldevicesincombinationwith,forexample,tamperingalarms,motiondetection,event

triggering,timelapserecordingandalarmnotications.Inadditiontothe0VDCreferencepointandpower(DCoutput),theI/O

connectorprovidestheinterfaceto:

•Digitaloutput—ForconnectingexternaldevicessuchasrelaysandLEDs.Connecteddevicescanbeactivatedbythe

VAPIX®ApplicationProgrammingInterface,outputbuttonsontheLiveViewpageorbyanActionRule.Theoutput

willshowasactive(shownunderSystemOptions>Port&Devices>PortStatus)ifthealarmdeviceisactivated.

•Digitalinput—Analarminputforconnectingdevicesthatcantogglebetweenanopenandclosedcircuit,for

example:PIRs,door/windowcontacts,glassbreakdetectors,etc.Whenasignalisreceivedthestatechangesand

theinputbecomesactive(shownunderSystemOptions>Port&Devices>PortStatus).

FunctionPinNotes

Specications

0VDC(-)

DCoutput

Canbeusedtopowerauxiliaryequipment.

Note:Thispincanonlybeusedaspowerout.

3.3VDC

Maxload=250mA

Digitalinput–Connecttopin1toactivate,orleave

oating(unconnected)todeactivate.

0tomax40VDC

Congurable(Input

orOutput)

3–6

Digitaloutput–Connectedtopin1whenactivated,

oating(unconnected)whendeactivated.Ifusedwith

aninductiveload,e.g.arelay,adiodemustbeconnected

0tomax40VDC,open

drain,100mA
