Axis S22 Series User Manual

AXISCameraStationS22ApplianceSeries
Managethebuilt-inswitch
Category
ItemDescription
ActiveportsThenumberofportsthatareinuse.
PortsusingPoEThenumberofportswithPoEenabledthatareinuse.
Portssummary
LockedportsThenumberofportsthatarelocked.
CurrentPoEusage
ThetotalpowerinwattsandpercentageconsumedbythePoEdevices.
Clicktheporttoseethedetailsabouttheport.
ActiveTheportisinuse.
InactiveTheportisreadytobeused.
Portstatus
BlockedTheportisblocked.
Portlist
ItemDescription
PortTheportnumberthatthedeviceisconnectedto.
DeviceThenameofthedeviceconnectedtotheport.
IPaddressTheIPaddressofthedeviceconnectedtotheport.
PoEDisplaysthePoEstatus.YoucanclicktheicontoturnonorturnoffPoEontheport.
Powerconsumption(W)
Thepowerinwattsconsumedbythedeviceconnectedtotheport.
Upstream(Mbit/s)
Theaveragedatarateinmegabitspersecondforoutbounddataontheport.
Downstream(Mbit/s)
Theaveragedatarateinmegabitspersecondforinbounddataontheport.
MACaddressTheMACaddressofthedeviceconnectedtotheport.
LockDisplayswhethertheportislocked.Youcanclicktheicontolockorunlocktheport.
TurnonandturnoffPoE
TurnonPoEonaport
1.Intheswitch’smanagementpage,clickOverview.
2.InthePoEcolumn,click
toturnonPoEonthespecicport.
TurnonPoEonallports
1.Intheswitch’smanagementpage,clickOverview.
2.Click
andselectTurnonPoEonallports.
TurnoffPoEonaport
1.Intheswitch’smanagementpage,clickOverview.
2.InthePoEcolumn,click
toturnoffPoEonthespecicport.
TurnoffPoEonallports
1.Intheswitch’smanagementpage,clickOverview.
2.Click
andselectTurnoffPoEonallports.
